5500KG Water Well Geological Exploration Drilling Rig

Product Details

Place of Origin: CHINA

Brand Name: OEM

Certification: ISO,CE

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: Negotiation

Packaging Details: Wooden cases standard export package

Delivery Time: 10-20 days working days

Payment Terms: T/T, L/C, T/T, Western Union

Supply Ability: Based on the detailed quotation

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                    200m Geological Drilling Rig Machine, Geotechnical Exploration Drilling Rig, Water Well Geotechnical Drill Rig


Type:	Geological Drilling Rig	Voltage:	380V
Dimension(LWH):	385015002250MM	Usage:	Water Well
Power Type:	Diesel 58-65KW	Weight:	5500KG
Certification:	ISO9001	Application:	Water Well Drilling / Core Drilling

Type:	Geological Drilling Rig
Voltage:	380V
Dimension(LWH):	385015002250MM
Usage:	Water Well
Power Type:	Diesel 58-65KW
Weight:	5500KG
Certification:	ISO9001
Application:	Water Well Drilling / Core Drilling

5500KG Water Well Geological Exploration Drilling Rig

5500KG Water Well Geological Exploration Drilling Rig

Application

Geology general check exploration, Earth physics exploration, Road and high layer building ground survey, Well, Blast opening et cetera drilling engineering, civil wells and earth central air conditioner ,etc..

Product Description:

Drill rig specification
Drilling depth	180m-200m
Drilling Diameter	140-325mm
Drilling rod diameter	76mm ; 89mm
Drilling rod length	1.5m; 2.0m; 3.0m
One-time propulsion length	3300mm
Dimensions(L×W×H)	385015002250 (mm)
Weight	5500kg/set
Walking speed	0-2.5 km/h
Climbing angles	30Max.
Minimum distance between ground	250mm
Using air Pressure	1.7-3.5Mpa
Host Power	58-65KW
Air consumption	17-35cbm/min
Swing torque	8500-10000 N.M
Rig lifting force	24T
Swing speed	45-115rpm
Air Compressor Flow	29cbm;23kg

Our Services:

1. Drill pipe strictly according to ISO9001 standard

2. If you found to quality problems within one month of the package returned.

3. All strictly according to the contract and fulfill the obligations and responsibilities

4. 24 hours online customer service,feel free contact us
